Bridgeway Lakes II Pump Station

The Bridgeway Lakes II Water Tank and Pump Station project includes the Structural Design of a 3-million-gallon water storage tank and a single-story rectangular pump station building.

Jump Ahead to Project Details

Project Details

The water storage tank is a 3 million gallon welded steel tank.  The tank shell is supported by a perimeter concrete ringwall foundation, and the tank’s interior columns are supported by concrete spread footings.

The pump station building consists of a wood-framed roof, concrete masonry block walls, a concrete slab-on-grade floor, and concrete spread footing foundations.

In addition to the water tank and pump station building, the Structural Design of a cast-in-place underground concrete meter vault and a concrete pad for the support and anchorage of a standby generator was provided.
